Cáp mạng thang máy Cat6 UTP Alantek 301-60FP80-DSBU

Cáp mạng thang máy Cat6 UTP Alantek 301-60FP80-DSBU
– Part Number: 301-60FP80-DSBU.
– Alantek Cat 6 UTP, Patch Cable, Stranded, 4-Pair Blue ( có shielded).
– Tiêu chuẩn: TIA/EIA 568B, ISO/IEC 11801, UL 444.
– Cuộn 305m.

Danh mục: CÁP THOẠI-CÁP MẠNG LAN

Mô tả
Đánh giá (0)

Specifications
Conductor
– Material: Stranded Bare Copper.
– Size: 24 AWG x 4 Pair.
– Construction: 7/0.203 ± 0.008mm.
Insulation
– Material: HDPE
– Min. Ave. Thickness: 0.15 mm.
– Min. Thickness at any point: 0.14 mm.
– Diameter: 0.09 ± 0.05 mm.
Core Assembly
– Core Twist: 2 core twist.
– Assembly Pair: 4 pair assembly.
Jacket
– Material: PVC.
– Thickness: 0.50 ± 0.2 mm.
– Min. Thickness at any point: 0.48 mm.
– Diameter: 5.6 ± 0.15 mm.
– Max. Tensile Load (Installation): 100N.
