Cáp mạng Alantek Cat6 UTP 4-pair

Giá: Liên hệ

Cáp mạng Alantek Cat6 UTP 4-pair Part
Number: 301-6008LG-03BU + Alantek Cat6 Twisted Pair Cable is designed to support high-bandwidth application up to 10Gigabit Ethernet. The cable is composed of 23 AWG bare solid copper conductors insulated with High Density Polyethylene (HDPE) insulation. For the unshielded cable, the 4 twisted pairs are separated by a flexible PE separator and the cable is completed with an Outer Jacket. Horizontal wiring, suitable for application up to 10 Gigabit Ethernet. +Packaging: 305m reel in a carton box.

Chat Zalo hoặc gọi Hotline - Hỗ trợ 24/7

Cam kết

Đảm bảo hàng chính hãng, đầy đủ CO, CQ
Miễn phí đổi trả khi hàng lỗi từ nhà sản xuất
Giải quyết mọi thông tin và đáp ứng mọi nhu cầu

Danh mục: CÁP THOẠI-CÁP MẠNG LAN

Mô tả
Đánh giá (0)

Number: 301-6008LG-03BU + Alantek Cat6 Twisted Pair Cable is designed to support high-bandwidth application up to 10Gigabit Ethernet. The cable is composed of 23 AWG bare solid copper conductors insulated with High Density Polyethylene (HDPE) insulation. For the unshielded cable, the 4 twisted pairs are separated by a flexible PE separator and the cable is completed with an Outer Jacket. Horizontal wiring, suitable for application up to 10 Gigabit Ethernet. +Packaging: 305m reel in a carton box.

Cable Type	Cat 6 UTP
Color	Blue
Weight	15000 kg
Standards	TIA/EIA 568B, ISO/IEC 11801, UL 444
Conductor Material	Solid Bare Copper
	Size: 23 AWG x 4 pairs
	Construction: 1/0.56 ± 0.01 mm
Conductor Insulation	Material: HDPE
	Min. Ave. Thickness: 0.23 mm
	Min. Thickness at any point: 0.22 mm
	Diameter: 1.03 ± 0.01 mm
Cable Jacket	Material: PVC
	Min. Ave. Thickness: 0.52 ± 0.02 mm
	Min. Thickness at any point: 0.50 mm
	Diameter: 6.4 ± 0.2 mm
